HPC Laser Ltd - card cut samples on co2 laser laserscript cutter

Cutting card samples on our HPC Laser  Laserscript LS6090 PRO speed 40 power 22 ....

Ask for a sample pack its got one of these in ! or book a Friday Demo slot and we will show you this and other things you can do.
see www.hpclaser.co.uk

HPC Laser Ltd - Signlink magazine advert co2 laserscript

Here is our latest ad in Sign link Magazine we are exhibiting at Sign link 2017 11th-13 October at The International Centre in Telford come and see the machines in action !!!

Paper and card cutting by HPC Laser Ltd

Todays samples cut on Laserscript 6090 at HPC laser......
Fast cutting on 20% power
Thanks for looking

Architectural Models om LS6090 From HPC Laser

Architectural model for final year project picture from Liverpool University cut on a HPC laser Laserscript 6090 Pro.
Very popular and outstanding detail in perspex and MDF

HPC Laser Ltd Support and warranty

All our HPC Laser PRO (Laserscript) laser machines are supplied with 12 months to 3 years onsite warranty, and unlimited technical support via phone and email, unlike many other UK suppliers who only offer parts only warranty.

We have a fleet of 5 vans on the road throughout the week covering the UK nationwide and keep a full range of spares in stock which can generally be dispatched by courier for next working day delivery.

HPC Laser Ltd supporting Bee Strong Bee Manchester fundraising

Bee Strong Bee Manchester

A West Yorkshire Year 9 student, Millie Fraser, wanted to do something to raise money and show support to the victims of last month’s Manchester bombings.  Millie had the idea of making Bee pin badges (the symbol of Manchester), and with the help the Art Teacher Megan Needham at her school in Rishworth, near Halifax, laser cut and produced 30 Perspex® Acrylic badges which she sold within an hour of being made.

With many more requests for badges, Millie’s mum Kim soon contacted local businesses for help and a local laser cutting machine supplier, HPC Laser, quickly offered to cut a new batch of 5000 yellow Perspex® acrylic Bee shapes using their industrial lasers.  With the help of family and friends this second batch was promptly produced and almost all Bees have already been sold with over £15,000 raised for the Manchester Red Cross appeal.

We spoke to Kim today who had a lined up dedicated team of 40 family and friends to help make a fresh batch of badges to keep up with the extraordinary demand as their campaign continues to grow on social media.

The Bee badges are now being distributed by over 40 local businesses including high street chains and the emergency services for a donation of £5 or more.

Perspex Distribution have been happy to supply more yellow Perspex® acrylic to the campaign to as the team try to keep up with demand as they have high hopes to double their fundraising total in the near future.

Please visit their Facebook campaign page @BeeStrongBeeManchester which will continue to be updated with their latest campaign news and badge distribution points.

HPC Laser Ltd - Machine Stripdown

All of our co2 PRO cabinet laser machines can be separated in half in order to fit through a standard doorway.
This means that machines can easily be installed on levels other than ground floor.

HPC Laser Ltd (Laserscript) cw3000 vs cw4000 water chiller units

There are two chiller units that HPC Lasers LTD sells, the cw3000 (suitable for models up to 50w) and the cw4000 unit (suitable for models up to 180w).

The cw3000 uses a fan to blow air onto the water kept in the chiller this means that the water will not necessarily be cooled, in this type of chiller the water temperature will tend to match that of the room.

The cw4000 unit contains refrigerator gasses and does cool the recirculating water circulating

Filling

Both the cw4000 and cw3000 have a capacity of 5 Litres and should be filled to just above the cooling coils

Temperature

Our chiller units are set up to maintain the water temperature at a constant 18 degrees the temperature is likely to increase under intensive use the chiller will alert the user with a beeping sound if the temperature exceeds 21 degrees and will display the error message E02 Should this error message be displayed the laser machine should be stopped immediately and allowed to cool.

If the temperature progressively loses its ability to cool then it may need its refrigerator gasses replacing. HPC Laser LTD can provide this service.

Flow

The chiller unit has its own pump if a chiller unit is fitted the standard pump is no longer required.

The chiller unit monitors the flow rate of water and it will emit a warning sound and display the error message E05 if the flow rate is too low, this could be caused by kinks in the water tubing or blockages in the piping, if the error message is displayed checked all the water pipes for kinks or tight turns and check the water quality, if the water is murky it should be replaced.

Available from UK stock and delivered via courier usually within 2 to 3 working days of your order.

Friday demonstrations at HPC Laser Ltd

If you would like to see one of our co2 laser systems, fiber laser cutter, or CNC routers in action please call (01422 310800) to book a demonstration.

Demonstrations are held every Friday at our factory showroom in Elland, West Yorkshire.

The demonstrations generally last between  1-2 hours and you are welcome to bring your own file and material should there be a certain application you would like to test.

HPC Laser Ltd (Laserscript) co2 Lasers RF and Glass Tubes

Lasers RF and Glass Tubes



CO₂   (carbon dioxide) lasers emit invisible radiation in the infra-red region of the spectrum, wavelength 10.6 microns. There are several types mainly RF laser tubes, including solid state versions which cost typically £3k -£5k and have lifetimes of the order of 6 -10,000 hours. We can supply these already fitted to our machine, typically doubling the cost of a 600 x 900 mm bed cutter/engraver. They are cooled by blowing air rapidly over them and can thus be noisy. Obviously they cost several thousand pounds to replace and re-gas at £1800 -£2000 which with a school budget has been hard to find for some of our customers.
The lasers we usually use are made of glass and can be replaced for about £250. They last typically 1500 hours but can last much longer. Seven years ago we supplied a machine fitted with such a laser and it is still in regular use, for several hours each day. The tube fitted to a new machine is guaranteed for three months and can be fitted by a reasonably skilled person as, apart from the mechanical holding system, it only requires two simple joints.

The joints are best sealed with a special silicone compound to reduce the chance of high voltage breakdowns. Glass tubes are water cooled, using a simple system with a small pump and reservoir in which the water is allowed to cool before re-entering the laser. For machines used intensively, say several hours each day, a water chiller will be needed, ours have a refrigerant and radiator to chill the water reservoir.

We now can offer a long life selection of tubes with 80watt,100watt,150watt with a lifespan of 10,000 hours this is a first in the U.K with a competitive price of less than £1500.00 to upgrade with tube and power supply.

Model Length (mm) Diameter (mm) Rated Power (W) Peak Power (W) 35w 745 55 35 40 40w 1000 55 40 50 60w 1200 55 60 80 80w 1600 60 80 100

Laser Ply (Laserable plywood)

Due to our commitment to keep production budgets down and make your life as easy as possible we supply a range of laser cutter substrates such as laser ply, perspex, laminates, slate coasters and various other laserable materials.

Our Laser ply has different glue to normal interior or exterior ply, this reduces the burning marks on the ply itself which should be a light brown and not really dark and charred looking. Also it reduces the amount of smoke and goo that comes out when cutting which is better for the lasers optics and cutting power.

The fumes from the 'normal' product can be harmful and can damage the equipment.

Our plywood has been tested and approved to meets ARB requirements.

LS6840 PRO EDITION LASER ENGRAVER AND CUTTER
